? Outdoor or indoor use.
? For use with single wire armour ‘W’, wire braid ‘X’ and steel tape armour ‘Z’ elastomer and plastic insulated cables.
? For particular use with:-
a) Cable inner sheaths that are not effectively filled, compact and/or circular, have tape bedding or have hygroscopic fillers.
b) Cables that exhibit ‘cold flow’ characteristics.
c) Enclosures containing an ignition source in gas group IIC areas or containing an ignition source in a Zone 1 area.
? Provides a barrier seal between the individual insulated cores within the cable and prevents entry of the products of an explosion into the cable.
? Provides armour clamping, using one clamping arrangementfor all armour/braid types.
? Provides an outer deluge seal to prevent moisture ingress to the cable armour/braid.
? Provides a cable retention and low smoke and fume, zero halogen seal onto the cables outer sheath.
